商品描述
Product Description
Datasheet
Datasheet | ||||
Model Name | SPF 3500 ES | SPF 5000 ES | ||
INVERTER OUTPUT | ||||
Recommended max. PV power | 3500VA/ 3500W | 5000VA/ 5000W | ||
Parallel Capability | Yes, 6 units maximum | |||
AC Voltage Regulation | 230VAC ± 5% @ 50/60Hz | |||
Surge Power | 7000VA | 10000VA | ||
Efficiency (Peak) | 93% | |||
Waveform | Pure sine wave | |||
Transfer Time | 10ms typical, 20ms Max | |||
SOLAR CHARGER | ||||
Maximum PV Array Power | 4500W | 6000W | ||
MPPT Range @ Operating Voltage | 120VDC ~ 430VDC | |||
Number of Independent MPP Trackers/ | 1/1 | |||
Maximum PV Array Open | 450VDC
| |||
Maximum Solar Charge Current
| 80A | 100A | ||
AC CHARGER | ||||
Charge Current | 60A | 80A | ||
230 VAC | 230 VAC | |||
Frequency Range | 50Hz/60Hz (Auto sensing) | |||
PHYSICAL | ||||
Protection Degree | IP20 | |||
Dimension (W/H/D) | 330/485/135mm | |||
Net Weight | 12kg | |||
The product description
1. LCD display | 2. Status indicator |
3. Charging indicator | 4. Fault indicator |
5. Function buttons | 6. AC input |
7. WiFi/GPRS communication port | 8. USB communication port |
9. BMS communication port (support CAN/RS485 protocol) | 10. RS485 communication port(for expansion) |
11. Dry contact | 12. PV input |
13. Power on/off switch | 14. Battery input |
15. Parallel communication ports | 16.Current sharing ports |
17. AC output | 18. Circuit breaker |
*Rated power 3.5KW to 5KW, power factor 1
*MPPT ranges 120V~430V, 450Voc
*High frequency inverter with small size and light weight
*Pure sine wave AC output
*Solar and utility grid can power loads at the same time
*With CAN/RS485 for BMS communication
*With the ability to work without battery
*Parallel operation up to 6 unit (only with battery connected)
*WIFI/ GPRS remote monitoring (optional)
This is a multifunctional off grid solar inverter, integrated with a MPPT solar charge controller, a high frequency pure sine wave inverter and a UPS function module in one machine, which is perfect for off grid backup power and self-consumption applications.This inverter can work with or without batteries.
Company Profile
Growatt was founded in 2010 and is a worldwide leader of smart energy solutions.
Growatt is the No.1 residential solar inverter supplier and is also one of the top 3 PV inverter suppliers for distributed
generation solar energy since 2018 and ranks among global top 10 PV inverter suppliers. The World's Manufacturer provides of residential, commercial and utility photovoltaic inverters, energy storage, microgrid systems and smart energy management solutions.
Construction case
Product packaging
*The unit x 1
*User manual x 1
*Communication cable x 1
*Current sharing cable x 1
*Parallel communication cable x 1
